The Xilinx XCZU9EG-2FFVB1156I is a heterogeneous system-on-chip (SoC) device from Xilinx. Here are some important details regarding this IC:


  • Manufacturer: Xilinx
  • Part Number: XCZU9EG-2FFVB1156I
  • Type: SoC (System-on-Chip)
  • Processing Cores: ARM Cortex-A53 application processor alongside Xilinx programmable logic fabric
  • Package/Case: 1156-FCBGA (Flip Chip Ball Grid Array)
  • Features: Integrated ARM multi-core processors, programmable logic fabric, memory controllers, and various I/O interfaces.
  • DataSheet



The XCZU9EG-2FFVB1156I is designed to offer a combination of traditional processors with the flexibility and reconfigurability of FPGA (Field-Programmable Gate Array) technology. This combines the processing power of ARM cores with the programmable logic fabric to provide a versatile and powerful platform for a wide range of applications.


These powerful SoC devices are extensively utilized in applications that demand a high level of processing performance and the flexibility to handle custom and evolving functionalities. Common applications include:

  • High-performance data processing applications
  • Embedded systems in industrial automation and control
  • Automotive systems and driver assistance platforms
  • Aerospace and defense applications
  • High-speed communications and networking

Key Components:

  • ARM Cortex-A53 Core: This is a power-efficient, high-performance ARMv8-A 64-bit processor core, often used for running application-level software in various embedded systems.
  • Programmable Logic Fabric: This provides the ability to implement custom hardware accelerators, custom interfaces, specialized functions, and reconfigurable logic tailored to specific application requirements.
  • Memory Controllers and I/O Interfaces: Integrated interfaces and controllers for interfacing with various memory types and external devices, ensuring seamless connectivity within the system.

Development and Programming:

Xilinx provides development tools such as Vivado Design Suite, which supports development for these SoC devices. It includes synthesis, place-and-route, and software development tools tailored to work with the ARM processors alongside the programmable logic fabric.


The XCZU9EG-2FFVB1156I from Xilinx represents a powerful and flexible computing platform that integrates ARM application processors with programmable logic. It is ideal for applications demanding a balance between high-performance processing and adaptability to evolving requirements. It is important for developers to refer to the device datasheet, user guides, and reference designs provided by Xilinx to utilize the features and capabilities of this SoC effectively in their designs.
