STM32H747XIH6 Microcontroller: Features, Applications and Datasheet


The STM32H747XIH6 is a microcontroller from STMicroelectronics, belonging to the STM32H7 series, which is based on the Arm Cortex-M7 and Cortex-M4 cores. Here's some information about its features, potential applications, and datasheet availability:



  1. Processor Core:

    • Dual-core architecture with an Arm Cortex-M7 running at up to 480 MHz and an Arm Cortex-M4 running at up to 240 MHz
  2. Memory:

    • Up to 2 MB of Flash memory
    • Up to 1 MB of RAM
  3. Peripherals:

    • Ethernet MAC
    • USB OTG (On-The-Go)
    • CAN FD
    • Multiple serial interfaces (UART, SPI, I2C)
    • ADC and DAC converters
    • Timers
    • SDIO
    • Crypto/Hash processor
  4. Security:

    • Secure boot, Secure firmware, Secure firmware update
  5. Power Management:

    • Multiple low-power modes
    • Power efficiency features
  6. Analog:

    • Analog-to-Digital Converter (ADC) with high resolution
    • Digital filters for sigma-delta modulators (DFSDM)
  7. Connectivity:

    • Ethernet MAC
  8. Operating Conditions:

    • Wide temperature range
    • Wide operating voltage range
  9. Packages:

    • Available in various package types
  10. Development Tools:

    • Supported by comprehensive development tools and software ecosystem from STMicroelectronics.


Potential Applications:

  1. Industrial Automation and Control:

    • Industrial control systems
    • Motor control applications
    • Robotics
  2. Consumer Electronics:

    • Smart home devices
    • Wearable devices
    • Multimedia devices
  3. Communications and Networking:

    • Routers and gateways
    • IoT (Internet of Things) devices
    • Network switches
  4. Automotive:

    • Infotainment systems
    • Advanced driver-assistance systems (ADAS)
    • Engine control units
  5. Medical Devices:

    • Patient monitoring systems
    • Imaging equipment
    • Diagnostic devices
  6. Aerospace and Defense:

    • Avionics systems
    • Military applications
    • Unmanned aerial vehicles (UAVs)


The datasheet for the STM32H747XIH6 pdf microcontroller can be obtained directly from STMicroelectronics' website, or through their distributors. It contains detailed information about the microcontroller's electrical characteristics, memory, peripherals, and package details.

You may visit the STMicroelectronics website, navigate to the STM32H747XIH6 product page, and locate the resources section where you can download the datasheet. If you have trouble finding this information, consider reaching out to their customer support for further assistance.
